技術特征
材料：碳鋼高溫淬火處理。
規格：1/4"-2"
螺紋：NPT,BSP（G）
表面處理：高溫鍍灰鎳，更耐腐蝕。
密封：丁腈橡膠（其它密封材料請垂詢）
工作溫度：-25℃~+125℃ 符合ISO6028標準
|
DN |
CH1 |
CH2 |
OE |
L1 |
L2 |
L3 |
F |
陰接頭(F) |
陽接頭(M) |
|
6 |
22 |
22 |
28 |
100 |
59 |
52 |
G 1/4 " |
PLT4.0606.112 |
PLT4.0606.113 |
|
|
|
|
|
|
|
|
1/4 NPT |
PLT4.0606.012 |
PLT4.0606.013 |
|
|
|
|
|||||||
|
G 3/8 " |
PLT4.0610.112 |
PLT4.0610.113 |
|||||||
|
|
|
|
|||||||
|
3/8 NPT |
PLT4.0610.012 |
PLT4.0610.013 |
|||||||
|
|
|
|
|||||||
|
9/16 UNF |
PLT4.0615.032 |
PLT4.0615.033 |
|||||||
|
|
|
|
|||||||
|
M16×1.5 |
PLT4.0616.102 |
PLT4.0616.103 |
|||||||
|
|
|
|
|||||||
|
M18×1.5 |
PLT4.0618.102 |
PLT4.0618.103 |
|||||||
|
13 |
30 |
30 |
32 |
118 |
73 |
61 |
G 3/8" |
PLT4.1310.112 |
PLT4.1310.113 |
|
|
|
|
|
121 |
73 |
64 |
3/8 NPT |
PLT4.1310.012 |
PLT4.1310.013 |
|
|
|
|
|
118 |
73 |
61 |
G 1/2" |
PLT4.1313.112 |
PLT4.1313.113 |
|
|
|
|
|
121 |
73 |
64 |
1/2 NPT |
PLT4.1313.012 |
PLT4.1313.013 |
|
|
|
|
|
118 |
73 |
61 |
9/16 UNF |
PLT4.1315.032 |
PLT4.1315.033 |
|
13 |
|
|
|
|
|
|
M16×1.5 |
PLT4.1316.102 |
PLT4.1316.103 |
|
|
|
|
|||||||
|
M18×1.5 |
PLT4.1318.102 |
PLT4.1318.103 |
|||||||
|
|
|
|
|||||||
|
3/4 UNF |
PLT4.1319.032 |
PLT4.1319.033 |
|||||||
|
|
|
|
|||||||
|
M22×1.5 |
PLT4.1322.102 |
PLT4.1322.103 |
|||||||
|
20 |
36 |
36 |
38 |
140 |
84 |
73 |
G 1/2" |
PLT4.2013.112 |
PLT4.2013.113 |
|
|
|
|
|
141 |
84 |
74 |
1/2 NPT |
PLT4.2013.012 |
PLT4.2013.013 |
|
|
|
|
|
133 |
80 |
70 |
3/4 UNF |
PLT4.2019.032 |
PLT4.2019.033 |
|
|
|
|
|
142 |
84 |
75 |
G 3/4" |
PLT4.2019.112 |
PLT4.2019.113 |
|
|
|
|
|
142 |
84 |
75 |
3/4 NPT |
PLT4.2019.012 |
PLT4.2019.013 |
|
|
|
|
|
137 |
83 |
71 |
M22×1.5 |
PLT4.2022.102 |
PLT4.2022.103 |
|
|
|
|
|
140 |
82 |
75 |
7/8 UNF |
PLT4.2023.032 |
PLT4.2023.033 |
|
|
|
|
|
142 |
84 |
75 |
M26×1.5 |
PLT4.2026.102 |
PLT4.2026.103 |
|
|
|
|
|
|
|
|
1-1/16 UNF |
PLT4.2027.032 |
PLT4.2027.033 |
|
22 |
36 |
36 |
42 |
137 |
82 |
73 |
G 1/2 " |
PLT4.2213.112 |
PLT4.2213.113 |
|
|
|
|
|
|
|
|
1/2 NPT |
PLT4.2213.012 |
PLT4.2213.013 |
|
|
|
|
|
134 |
82 |
70 |
3/4 UNF |
PLT4.2219.032 |
PLT4.2219.033 |
|
|
|
|
|
143 |
86 |
75 |
G 3/4 " |
PLT4.2219.112 |
PLT4.2219.113 |
|
|
|
|
|
|
|
|
3/4 NPT |
PLT4.2219.012 |
PLT4.2219.013 |
|
|
|
|
|
135 |
82 |
71 |
M22×1.5 |
PLT4.2222.102 |
PLT4.2222.103 |
|
|
|
|
|
143 |
86 |
75 |
7/8 UNF |
PLT4.2223.032 |
PLT4.2223.033 |
|
|
|
|
|
|
|
|
M26×1.5 |
PLT4.2226.102 |
PLT4.2226.103 |
|
|
|
|
|||||||
|
1-1/16 UNF |
PLT4.2227.032 |
PLT4.2227.033 |
|||||||
|
25 |
41 |
41 |
48 |
159 |
95 |
86 |
G 3/4 " |
PLT4.2519.112 |
PLT4.2519.113 |
|
|
|
|
|
|
|
|
3/4 NPT |
PLT4.2519.012 |
PLT4.2519.013 |
|
|
|
|
|
162 |
98 |
86 |
G 1 " |
PLT4.2525.112 |
PLT4.2525.113 |
|
|
|
|
|
|
|
|
1 NPT |
PLT4.2525.012 |
PLT4.2525.013 |
|
|
|
|
|
160 |
95 |
87 |
1-5/16 UNF |
PLT4.2533.032 |
PLT4.2533.033 |
|
30 |
55 |
55 |
55 |
177 |
110 |
90 |
G 1-1/4 " |
PLT4.3031.112 |
PLT4.3031.113 |
|
|
|
|
|
|
|
|
1-1/4 NPT |
PLT4.3031.012 |
PLT4.3031.013 |
|
|
|
|
|||||||
|
1-5/8 UNF |
PLT4.3041.032 |
PLT4.3041.033 |
